UBNT Wave Nano, 60 GHz
Compare Set Watchdog

UBNT Wave Nano, 60 GHz

Ubnt Wave Nano is a 60GHz client unit with an antenna gain of 41 dBI for PTMP connections.More information

Producer
  Ubiquiti

Part No.


Wave-Nano


Code
 00072786
Warranty
24 Month
Your price exc. VAT
246.21 EUR exc. VAT
VAT
21%
Your price inc. VAT
297.92 EUR  inc. VAT


    Ask for a better price

    Your e-mail
    Phone
    Quantity
    Comment

    Description

    Ubnt Wave Nano is a 60GHz client unit for PTMP connections . It is a powerful outdoor unit of the robust design and compact dimensions with a 41 dBI communication with AP speed to 2 Gbps (1 GBPS duplex) at 16 Qam , making it the ideal ISP. The width of the channel can be 1080 and 2160 MHz . For the best availability, 5GHz Radio (802.11AX WiFi 6) is present as a backup .
    The initial settings can be easily made from the smartphone using Bluetooth and mobile applications. The unit is longer fitted with integrated GPS antenna.
    For data transmission and power supply, a gigabit LAN port with passive poe 48/24 in DC.


    Package content

    • device
    • mast bracket with precise role (for mast 25 to 63.5 mm)
    • Gigabit PoE power adapter 48 V/0.65 and
    • power cable

    Parameters

    Antenna gain 5 GHz (dBi) 19
    Antenna gain 60 GHz (dBi) 41
    Bluetooth Yes
    Consumption 20
    CPU - frequency (MHz) 1000
    Encryption WPA2 AES
    IP protection IPX6
    Management Yes
    Max. počet klientů 24
    Operating systém airOS
    Platforms UISP
    Počet CPU jader 2
    Power Supply PoE
    Processor ARM Cortex A53
    RAM 512 MB
    XPIC No

    Ethernet parameters

    LAN port speed 1 Gbps
    Network interface (Mbps) 10/100/1000
    Number od RJ45 ports 1

    Physical parameters

    Depth (mm) 113.5
    Design Outdoor, Na stožár
    Height (mm) 256.5
    Operating Temperature -40° až +60 °C
    Počet LAN portů 1
    Weight (kg) 1.2
    Width (mm) 256.5

    Wireless parameters

    Frequency 60 GHz
    Operating mode Client
    WiFi transfer rate - 5 GHz [Mbps]: 1201
    WIFI transfer rate - 60 GHz [Mbps] 2000
