Grandway FHS1D03 Mini Optical Laser Source

FHS light sources offer excellent reliability and mobility for accurate optical fiber testing. One output optical port offers a stable, reliable and powerful laser source using two wavelengths. This compact unit can work in both CW (Continuous) and"Modulated". The battery status indicator is also integrated for user comfort.

FHS1 models are a low-cost solution designed for all basic optical fiber tests. With a small size and weight, they are a handy helper of all users working with optical nails.

properties:

• model FHS1D03
• Laser type LD
• Output power-5dbm ± 0.5 dB
• operating temperature-10 ° C-50 ° C
• storage temperature-20 ° C-70 ° C
• Dimensions (mm) 115 x 65 x 30
• Weight 140g
• output wavelength (nm) 850/1300
• Central wavelength 850 ± 10nm/1300 ± 20nm
• spectral width 3nm
• output frequency (Hz) 270/1k/2k
• Output stability short-term <0.1db
• Output stability long-term <0.2dB
• automatic shutdown yes
• backlighting yes

The package contains only a connector for connecting the FC connector. To connect LC or. The SC connector must be purchased
