Grandway FHS2Q02F Optical laser source 1310/1490/1550/1625nm
Source of invisible light with 4 wavelengthsMore information
Producer
Grandway
Part No.
FHS2Q02F
Code
00034626
Warranty
12 Month
Order
Your price exc. VAT
698.18 EUR
exc. VAT
VAT
21%
Your price inc. VAT
844.80 EUR
inc. VAT
Ask for a better price
Parameters
| Backlight | Ano |
| Central wavelength | ±20nm |
| Dimensions (mm) | 160 x 76 x 45 |
| Laser type | LD |
| Long-term output stability | < ±0.1dB @1310,1550nm; ±0.2dB@850 & 1300&1490&1625 |
| Model | FHS2Q01F |
| Operating Temperature | -10° až +50°C |
| Output frequency (Hz) | 270/1K/2K |
| Output Power - Uplink (dBm) | -5dBm |
| Output wavelength (nm) | 850/1300/1310/1550 |
| Short-term output stability | < ±0.05dB @1310,1550nm; ±0.1dB@850 & 1300&1490&1625 |
| Spectral width | 3nm |
| Storage temperature | -20°C - 70°C |
| Turn off automatically | Ano |
|
Physical parameters |
|
|---|---|
| Weight (kg) | 0.27 |
Do you need help?
We will help you with product selection or technical problems.
(+420) 246 035 451
Information and orders
Jan Mencl
Product manager
+420 778 885 932
mencl@vanco.cz
Products classification
Product question
Product question
Do you need help?
We will help you with product selection or technical problems.
(+420) 246 035 451
Information and orders
Jan Mencl
Product manager
(+420) +420 778 885 932
mencl@vanco.cz
Related products1
Related products
GPSR
Last visited
Description
FHS2Q02F laser sources are able to use up to 4 wavelengths 1310/1490/1550/1625nm
The unit is equipped with automatic detection of a wavelength based on the use of an encypt protocol, which allows units from the FHP2 Power Meter to automatic recognition and use of suitable calibration parameters. This feature reduces the needs of communication between two techniques, simplifies measurements and reduces the risk of potential errors.
FHS light sources offer excellent reliability and mobility for accurate optical fiber testing. The output optical ports offer a stable, reliable and powerful laser source using given wavelengths. This compact unit can work in both CW (Continuous) and"Modulated". The battery status indicator is also integrated for user comfort.
properties:
Easy to use
practical packaging
Display backlight for work in dark environments
Integrated charging battery
1310/1490/1550/1625nm for SM fiber testing
3-year warranty
Specifications:
Model: FHS2Q02F
Laser type: LD
Output power:-5dbm ± 0.5 dB
Operating temperature:-10 ° C-50 ° C
storage temperature:-20 ° C-70 ° C
Dimensions (mm): 160 x 76 x 45
Weight: 270g
output wavelength (Nm): 1310/1490/1550/1625nm
spectral width: 5nm
Output frequency (Hz): 270/1k/2k
output stability short-term: <± 0.05db @1310,1550nm;
±0.1db@1490\u00261625
Long-term output stability: <± 0.1db @1310,1550nm;
±0.2db@1490\u00261625
Automatic shutdown Yes:
backlighting yes:
