Installation cable Solarix CAT6 FTP PVC, gray

This SLARIX-category 6-FTP-PVC-category is a high-quality cable designed for horizontal wiring of structured cabling, which meets and also exceeds the requirements specified in the international ANSI/TIA 568, ISO/IEC 11801 and EN 50173 for CLASS E, including all CLASS E, the latest additions.
The Solarix-Category 6 cables are supplied in shielded and uninhabited versions with different types of jackets-ie PVC (ECA reaction class), LSOH (ECA reaction class) or UV stable PE (FCA reaction class). The wires of these cables are made of high quality copper wire size AWG 23. Individual pairs are separated by plastic cross.
Like the other Solarix cables, the SXKD-6-FTP-PVC cable is marked by one by 1m in the range of 0 to 500m. The cable is supplied to high-fixed wooden coils on which all necessary product information, including barcodes, batch, description and the most important technical parameters.

parameters:

name	value
Category:	Cat6
Supported protocols:	1000BASET, 1000BASETX
Shielding:	foil around all 4 pairs
bandwidth (MHz):	250
Type and size of the wire:	copper wire 0, 565 mm
Insulation and wire diameter with insulation:	polyethylene 1.12 mm
Class Responding to Fire, Type of Manta:	ECA, PVC
jacket color:	gray RAL 7035
cable diameter (mm):	7.4
storage temperature (° C):	-20 to 60
Operating temperature (° C):	-20 to 60
Installation temperature (° C):	0 to 50
Package:	500 m, wooden coil
Package dimensions (diameter x height):	380 mm x 320 mm
