Smart PDU NETIO PowerCable 2PZ

Netio PowerBox 2PZ is on LAN and WiFi controlled smart PDU with 2 outputs. Each output can be turned on and off via the product interface. The materials and temperature ranges of the equipment predetermine for use in industries. Thanks compact ...More information

Producer

NETIO

Part No.

PowerCable 2PZ

Code

00072941

Warranty

24 Month

Availability

Availability in stores

Order

Your price exc. VAT

143.98 EUR exc. VAT

VAT

21%

Your price inc. VAT

174.21 EUR inc. VAT

Ask for a better price

Description

Netio Powerbox 2PZ is on LAN and WiFi controlled smart PDUs 2 outputs . Each output can be turned on and off via the product interface. The materials and temperature ranges of the equipment predetermine for use in industries. With compact dimensions, PDUs can be easily installed, for example, for screens, ceilings or other less accessible places.

Simply controlable
Netio PowerBox 2PZ smart power outlets allow you to control the site and support Netio Cloud. Supported protocols can be used for Open API communication (complete list V datasheet ) The logs are documented on the manufacturer's website. Each of the two electrical outputs can be turned on/off from the product website. The manufacturer supplies the mobile application, but thanks to the open API you can also use the recommended third-party mobile applications.

Web interface can be tested at http://powercable-2pz.netio-products.com/ (demo). Using Netio Cloud , outputs can be controlled from anywhere. Netio Cloud is a paid service, but uses SSL security and servers are located in Europe. As part of the new device, you can try 3 annual trial version free of charge.

gentle
IOC (Independent Output Control), Output status is not affected by LAN of the connection, restarting the network layer or firmware upgrade.

The unique feature of the PowerCable 2PZ is the function zvs This fundamentally limits the negative effect of the switching current (inrush current), precedes problems and protects the controlled device.

The Scheduler function turns off and on each electric output (110/230V max 16A) separately at the set time and day of the week. The delaying function will protect the electric circuit breaker after power failure. The PowerUP State parameter can define the status of each output immediately after power on (ON/OFF/LAST).

parameters:

name	value
LAN:	1x RJ45
wifi:	Yes
di (digital input):	No
Web:	Built-in Web Server
Mobile App:	Yes (Android, iOS)
consumption measurement:	No
Watchdog:	ping
M2M API protocols:	MODBUS/TCP, MQTT-FLEX (PLIN/TLS), Telnet, HTTP URL API, HTTP JSON, HTTP XML, SNMP V1/V3
LUA support:	No
Power input:	terminal block (2.5mm), 100-240 VAC (50/60 Hz)-max 16 and
Mechanical power switch:	No
Power output:	2x 230V/16A
ZVS (switching output when passing a voltage zero):	Yes
Dimensions:	125 x 73 x 204 mm
PowerUP State	ON/OFF/LAST STATE
Acoustic output:	No
Temperature range:	-20 ° C to +55 ° C
Custom Consumption of Device:	1-2 W
