RACK Triton, 19", 6U, 600x300mm, wall-mounted-RBA-06-AD2-CAX-A1

The switchboard doors are all-glass standard, but on request can be nationwide or with perforation.
The hinge system itself allows the door to open at an angle of almost 180 °. Doors can be easily removed.
Opensable parts of the switchboard allow easy access to the rear of the switchboard.
After unlocking the connecting locks, you can easily open the front of the switchboard.

parameters:

name	value
Type:	Wall-mounted, two-piece
pitch:	19"
Covering:	IP 30
doors:	glazed
height:	6U
width (mm):	600
depth (mm):	295
height (mm):	370
Color:	gray
Weight (g):	13 400
Max. Load (G):	25 000
Material:	Safety hardened glass thickness. 5 mm, steel sheet

Package content

key-front door 2x

screw 6x50 4x

pad 6.6 4x

dowel 10 4x

Floating nuts M6 8x

Anti-draft plug 1x
